StoVentec R


Ventilated Rainscreen Facade System



Overview

A ventilated rainscreen facade system with a seamless render finish - The StoVentec R system is fixed to the exterior wall with a highly-engineered adjustable aluminium sub-construction with cavity between the facade and the render carrier board. This can be part-filled with optional mineral fibre or other insulation as specified for effective external wall insulation. Thanks to the ventilation of the system, the substrate and optional insulation remain permanently dry, protected and functional.



With almost no limits to facade design due to the flexible sub construction, sustainable recycled glass carrier boards and the unlimited variety of finishing renders in any colour, StoVentec R allows for outstanding designs to be realised.








Brochure

Brochure
StoVentec R - Ventilated rainscreen facade system
PDF








Gallery

Click here for additional photos. Click on a thumbnail for a larger image.



StoVentec R - Victoria Uts-Sydney-StoVentec Student-housing-Germany Ventec-R img 3



Ventec-R img 4 Ventec-R img 4 Shopping center, StoVentec.



Click here to hide images.












StoVentec R

The StoVentec R system has been designed to suit just about any substrate, including porous concrete and timber framed buildings. Used both in the construction of new buildings and in refurbishment, the adjustable stainless steel sub-construction corrects uneven substrates up to 320mm and provides the ability to accommodate for curved structures. The ventilated cavity ensures the wall remains dry and breathes. The system components are adaptable to meet the needs of each individual project.



  • Adjustable stainless steel sub-construction up to 320mm.

  • The mineral fibre insulation board provides high thermal performance and fire protection.

  • Made of 96% recycled expanded glass granulate and reinforced on both sides with glass fibre mesh for superior impact resistance.

  • Optional inuslation.

  • Seamless rendered facade (minimal control joints).

  • Suitable for curved surfaces.

  • Complete supply and install.









StoVentec R
Click on each of the layers below to view the components of the System.







StoVentec System ventec_system_110 ventec_system_120 ventec_system_130 ventec_system_140 ventec_system_150 ventec_system_160 ventec_system_151 ventec_system_170



01

Substate:

A new development or cracked refurbishment, such as concrete block, brick, slab or timber.



02

Sub-construction:

Sub-construction consisting of aluminium profiles to fix the carrier boards in place. Anchored in the substrate with Sto approved fixings inaccordance with the New Zealand Building Code.



03

Optional Insulation:

Seamless exterior mineral wool or other insulation as specified. Thickness variable according to thermal insulation requirements.



04

Render carrier board:

StoVentec R carrier board, consisting of recycled glass (expanded glass granulate), with mesh reinforcement on both sides, thickness 12 mm, format 1.20 x 0.80 m and 1.20 x 2.40 m; low weight of approx. 6 kg/m2, of limited combustibility in accordance with DIN 4102, frost-resistant.



05

Reinforcement Fibre Render:

StoArmat Render, organic, cement free, ready-to-use bonding and reinforcing compound. Highly expandable, crack-resistant and highly resistant to mechanical stress.



06

Reinforcing mesh:

Sto Glass Fibre Mesh 4/7mm
Alkali-resistant reinforcing mesh, non-shifting with optimized capacity to absorb forces.



07

Finishing Render: Stolit range

Stolit (organic plaster) cement-free, ready-to-use finishing renders. Highly weather resistant, minimal susceptibility to soiling, highly elastic, resistant to mechanical stress. Selected StoColor IQ facade paints for intelligent solutions.

Alternative options consist of: Ceramics, glass mosaics, ashlar Frost-resistant and suitable for bonding directly on site, for broad design scope.



sto warranty

StoArmat 20+ Year Warranty with StoService Assurance












Finishes

Stolit: Coloured Finishing Renders

Stolit organic finishing renders are manufactured in Germany incorporating the latest technology; certified globally and successfully applied to rendered substrates in every climatic zone for over 50 years.



The Stolit range provides the perfect combination of properties: durable, strong, hard-wearing, impact-resistant, malleable, weather-resistant, colour-stable and highly resistant to microorganisms. In addition, its vapour permeability allows your building to breathe while still repelling water.





Coloured Self-Gauging Float Finish Renders:

StolitK 1.0mm StolitK 1.5mm StolitK 2.0mm StolitK 3.0mm

StolitK 1.0mm

StolitK 1.5mm

StolitK 2.0mm

StolitK 3.0mm



Coloured Fine Float, Sponge, or Light Adobe Finish Renders:

StolitK MP StolitK MP Natural Stolit Milano

Stolit MP

Stolit MP Natural

Stolit Milano












Facade Paints

The StoColor finish, a serviceable coating embodying intelligent technology for a range of surface functions to compliment the architectural structure and design. The StoColor System, with 800 shades or matched to any colour using the Sto Spectrometer, provides a clear framework and systematic approach to colour based on integrated layers, combining texture and colour for aesthetic appeal.





Product

StoColor Lotusan
The tried-and-tested facade paint with patented Lotus-Effect® technology for facades that stay clean for longer.

StoColor X-black
Strong colours for cool facades. Matt finish facade paint for dark coloured facades.

StoColor Maxicryl
Acrylic facade paint with high covering power for a natural look.

StoColor Lastic
Elastomeric durable facade paint.



Sto Paint






TDS / MSDS

sto detail expand



Download a TDS or MSDS



Render Carrier Board:



TDS
StoVentec Carrier Board
PDF



Reinforcement Mesh:



TDS
StoMesh 4mm
PDF
TDS
StoMesh 7mm
PDF



Reinforcement Render:



TDS / MSDS
StoArmat Render
PDF PDF



Finishing Renders:



TDS / MSDS
Stolit K 1.0mm
PDF PDF
TDS / MSDS
Stolit K 1.5mm
PDF PDF
TDS / MSDS
Stolit K 2.0mm
PDF PDF
TDS / MSDS
Stolit K 3.0mm
PDF PDF
TDS / MSDS
Stolit MP & MP Natural
PDF PDF
TDS / MSDS
Stolit Milano
PDF PDF



Coatings:



TDS / MSDS
StoColor X-black
PDF PDF
TDS / MSDS
StoColor Lotusan
PDF PDF
TDS / MSDS
StoColor Maxicryl
PDF PDF
TDS / MSDS
StoColor Lastic
PDF PDF




Specifications

sto detail expand

Download a Technical Specification



Sto can advise on how the StoVentec R system can meet the needs of your project. If you require a specification please contact us.




CAD or PDF Details

sto detail expand



Download a Detail Set



For a StoVentec R detail or set please contact us.










Disclaimer: These drawings have been issued as a guideline. The sequence work covers various building components, each trade is responsible to ensure their elements are fully installed, including all waterproofing / sealant / flashings as is applicable.
